Application

• Suitable for testing longer specimens like wire, cable, connecting rod, steel wire, steel cable, steel link, metal chain, chain assembly, spring, webbing, rope, anchor chain, hook, piping, metal fasteners…etc.
• Confirming to most international standards like ISO 7500-1, EN 10002-2, BS 1610, DIN 5122, ASTM E4, JIS 7721 / B 7733, GB 228-2010, JJG 139-1999, CNS 2111, 9471, 9470...etc.

Measurement Device

• Hydraulic control system or servo control hydraulic system. Apply high accuracy load cell.
• Testing gain force automatic switching function; if the capacity reach 100%, it automatically witch the large capacity.
• Accutacy : ≤ ±1% , Load Resolution :1/200,000 above
• Display a variety of experimental curves?Load-Elongation, Load-Time, Elongation-Time, Stress –Strain.

Control System

• Super powerful control function, with high intelligent computer system
  testing, application study, force application study.
• Closed-loop servo hydraulic control system
• Control Mode :
  1. Fixed displacement
  2. Fixed velocity
  3. Fixed load
  4. Constant load speed
  5. Constant strain speed
  6. Constant stress speed
  7.Stress > Strain speed
  8. Fixed velocity > Load
  9. Fixed velocity > Displacement
• Fixed velocity control range :
  Origin point ~ Max. stroke setting range : 0.5 ~ 80 mm/min
• Control mode of operation :
  Auto / Manual function available to switch off
• Emergency shut down button & overload protection (auto stop) functions equipped
• Setting of testing parameters :
  Database modularized
• Accuracy of load : ± 1 %
• Fixed veloctiy load control range : Full capacity 5 ~ 100% (F.S.)

Data Processing System

• Data acquisition and data-analysis / Clarification.
• Available to backup and modify the write / read path of database.
• SI unit and other conversion unit : N, kN, g, kg, ton. lb for force ; mm, cm, inch for length.
• Self-defined testing modules based upon any kind of standard test norms.
• Software password security protection ( optional )
• X BAR-R engineering diagram and SQC quality control diagram ( optional )
• Various kinds of software providing data manipulation and analysis.
